Analysis of water tube tiltmeter observation affected by reservoir load
-
摘要: 河北省易县地震台DSQ型水管倾斜仪NE向2022年2月14日以来观测数据曲线出现趋势下降E倾变化，年变观测数据曲线不同于往年。对该异常进行了分析，并结合三维集中荷载模型模拟计算结果表明：2022年2月14日—4月6日旺隆水库共泄流总库容量达到279.5万m3，造成倾斜变化理论值为1.27×10−7，高于倾斜干扰的限定指标1.455×10−8一个量级，推测此是造成易县台水管仪NE分量加速异常变化的主要因素。Abstract: The curve of DSQ water tube tiltmeter NE at Yixian seismic station in Hebei Province had a downward trend since February 14, 2022. The annual change curve was different from that of previous years. Combined with the simulation results of three-dimensional concentrated load model, it is shown that the total reservoir capacity of Wanglong reservoir reached 279.50×104 m3 from February 14 to April 6, 2022. The theoretical value of tilt change was 1.27×10−7 , which is higher than the limit index of tilt interference of 1.455×10−8, it was inferred as the main factor causing the abnormal change of NE component acceleration of water tube instrument at Yixian station.
-
Key words:
- water tube tiltmeter /
- load /
- reservoir /
- abnormal
-
图 3 易县台水管仪NE分量异常曲线
Figure 3. NE component anomaly curve of water meter at Yixian station
图 4 水库日泄流库容量与水管仪NE分量日值变化对比图
Figure 4. Comparison between daily discharge capacity of reservoir and daily variation of NE component of water meter
图 5 易县台地倾斜各分量分钟值图（2022年2月1日—4月30日）
Figure 5. Minute value map of various components of Yixian station tiltmeter （from February 1 to April 30, 2022）
表 1 易县台山洞地倾斜2022年2月14日—4月6日观测数据统计表
Table 1. Statistics of observation data of ground tilt of cave in Yixian station from February 14 to April 6, 2022
仪器名称 测项 变化量/ms 变化方向 水管倾斜仪 NS分量 661.52 S倾 EW分量 65.53 E倾 NE分量 155.29 E倾 垂直摆倾斜仪 NS分量 33.70 N倾 EW分量 12.00 E倾
下载: 导出CSV
-
[1] 陈开坊,李占录. 张北6.2级强震前易县台地形变临震异常[J]. 华北地震科学,1999,17(4):70-71Chen K F,Li Z L. Impending earthquake anomaly of topographic deformation at Yixian Station before Zhangbei M6.2 strong earthquake[J]. North China Earthquake Sciences,1999,17(4):70-71 [2] 陈建国,张娜,王秀文,等. 形变数字化资料对山西地区地震前兆反应研究[J]. 山西地震,2009(1):1-8Chen J G,Zhang N,Wang X W,et al. Study on the response of digital deformation data to earthquake precursor of Shanxi[J]. Earthquake Research in Shanxi,2009(1):1-8 [3] 苏树朋,李津津,张勤,等. 易县地震台形变资料对汶川8.0级大地震的反应[J]. 华北地震科学,2009,27(2):54-58Su S P,Li J J,Zhang Q,et al. The response of crustal deformation data in Yixian Seismic Station to Wenchuan M8.0 earthquake[J]. North China Earthquake Sciences,2009,27(2):54-58 [4] 张娜,龚燕民,李博. 洞体应变观测中荷载干扰实例分析[J]. 地震地磁观测与研究,2017,38(4):153-157Zhang N,Gong Y M,Li B. Case analysis of load interference of cave strain observation[J]. Seismological and Geomagnetic Observation and Research,2017,38(4):153-157 [5] 张磊,邵永新,曹井全,等. 蓟县台水管倾斜仪NS向加速北倾异常分析[J]. 大地测量与地球动力学,2016,36(4):372-376Zhang L,Shao Y X,Cao J Q,et al. Analysis of acceleration incline to North direction of water tube tilt-meter at Jixian Seismostation[J]. Journal of Geodesy and Geodynamics,2016,36(4):372-376 [6] 赵连勋. 旺隆水库成了聚宝盆[J]. 河北水利,1994(4):22-23Zhao L X. Wanglong Reservoir become a cornucopia[J]. Hebei Water Resources,1994(4):22-23 [7] 邱泽华. 倾斜观测载荷干扰源最小“安静”距离理论分析[J]. 地震,2004,24(4):80-86Qiu Z H. Theoretical study on the least“Quiet”distance between borehole tilt observatory site and surficial mechanical disturbance sources[J]. Earthquake,2004,24(4):80-86 [8] 刘澜波,郑香媛. 井水固体潮分析结果及其在地震预报中的应用[J]. 地震,1985,1(1):7-12Liu L B,Zheng X Y. The analysis results of water-well earth tides and their applications to earthquake prediction[J]. Earthquake,1985,1(1):7-12 -
