Software construction of data processing for cross fault flow deformation
-
摘要: 由于跨断层流动形变数据具有特殊性，其数据处理均为用户自己编制软件进行处理，缺少涵盖跨断层流动形变数据日常处理方法软件。为此，本文基于Windows系统、使用C#语言、MySQL数据库开发研制日常跨断层流动形变数据处理软件，不仅可以存储管理监测场地监测数据，而且具有多种数据包括不等间隔数据预处理、数据处理以及图像与辅助信息编辑输出等功能。该软件将进一步推动跨断层流动形变数据在防震减灾工作中发挥作用。Abstract: Due to the particularity of cross-fault flow deformation data, the data is usually processed by user’s own processing software, and there is a lack of software for daily processing of cross-fault flow deformation data. Based on this situation, the processing software for daily cross-fault flow deformation data is developed in view of the Windows system. Using C# language, MySQL database in this article, the processing software can not only store and monitor site monitoring data, but also has multiple functions including uneven interval data pre-processing, data processing, edit and output of image and auxiliary information etc. This processing software will further promote cross-fault flow deformation data to play a role in earthquake prevention and disaster reduction.
-
Key words:
- cross-fault flow deformation /
- unequal interval data /
- process
-
[1] 陆明勇,刘天海,黄宝森,等. 跨断层流动形变监测环境及监测技术探讨[J]. 大地测量与地球动力学,2011,31(5):141-145 [2] 屈佳,张四新. 基于GIS跨断层场地基础信息系统构建[J]. 国际地震动态,2014(4):27-34 doi: 10.3969/j.issn.0235-4975.2014.04.009 [3] 陆明勇,熊道慧,于海生,等. 首都圈地区跨断层流动形变基础与数据及其监测环境信息库的构建[J]. 国际地震动态,2015(10):32-38 doi: 10.3969/j.issn.0235-4975.2015.10.006 [4] 吴培稚, 刘天海, 陆明勇, 等. 跨断层测量的不等间隔数据处理[J]. 大地测量与地球动力学, 2019, 39(7):696-699 -
