Analysis on non-tectonic origin of linear scarps in alluvial-proluvial fan of the west bank of Xidong in Hexi Corridor
-
摘要: 构造、侵蚀与人为等多种因素均影响着冲洪积扇线性陡坎的形成和发现。结合无人机高分辨率遥感影像解译、地形地貌剖面分析、探槽开挖、工程地质剖面分析和音频大地电磁探测等多种方法，对河西走廊西洞西滩冲洪积扇发育的线性陡坎地貌由浅及深开展综合对比分析，得到如下结论：地形地貌剖面显示线性陡坎两侧地形高程递变平缓，未见变形现象；探槽揭示了线性陡坎两侧下伏的地层连续，底部地层近水平产出且产状明显小于顶部地层，未见地层错断现象；工程地质剖面表明线性陡坎两侧的Q3冲洪积砂卵砾石层顶面连续，未见地层错动现象；音频大地电磁探测结果显示线性陡坎两侧下伏基岩界面连续完整，未见断层通过迹象。因此，综合认为河西走廊西洞西滩冲洪积扇发育的线性陡坎地貌是由大磁窑河水侧向侵蚀作用形成的，而非构造作用所致。Abstract: The formation and discovery of linear scarps in alluvial-proluvial fan are affected by many factors, such as structure, erosion and human activities. In this paper, combined with the UAV high resolution remote sensing image interpretation, the topographic and the geomorphological profile analysis, the trench excavation, the engineering geological profile analysis and the audio magnetotelluric detection etc., we analyzed comprehensively the landform of the linear scarp developed in the alluvial-proluvial fan of the west bank of Xidong in Hexi Corridor from the shallow layer to the deep layer. The conclusions are as follows: the topographic and geomorphological profile indicates that the terrain elevation on both sides of the linear scarp is turning gradually flat without deformation; The trench reveals that the underlying strata on both sides of the linear scarp are continuous, and the bottom strata are nearly horizontal with the occurrence being significantly less than the top strata and there is no stratigraphic fault; The engineering geological section shows that the top surface of Q3 alluvial-proluvial sandy gravel layer on both sides of the linear scarp is continuous, and there is no formation dislocation; The audio magnetotelluric detection results show that the underlying bedrock interface on both sides of the linear scarp is continuous and complete, with no sign of fault passing. Therefore, it is concluded that the linear scarp landform developed in the alluvial-proluvial fan of the west bank of Xidong in Hexi Corridor is formed by not the tectonic effect rather than the lateral erosion of the Daciyao river.
-
图 1 研究区周边构造图和线性陡坎遥感解译图
Figure 1. Structural map of the surrounding area of the study area and the remote sensing interpretation map of the linear scarp
图 3 线性陡坎南部高分辨率遥感解译图和地貌图
Figure 3. High resolution remote sensing interpretation map and geomorphologic map of the south to the linear scarp
图 4 线性陡坎北部高分辨率遥感解译图和地貌图
Figure 4. High resolution remote sensing interpretation map and geomorphologic map of the north of the linear scarp
图 8 大磁窑河出山口附近高分辨遥感解译与河流阶地高程图
Figure 8. High-resolution remote sensing interpretation and river terrace elevation map near the outlet of Daciyao River
表 1 探槽剖面地层描述
Table 1. The description of trench
探槽
编号地层
编号地层特征描述 TC-1 U1 灰褐色砾石与土黄色粉砂混合堆积，厚0.5—0.7 m，偶含砾石，砾石粒径一般为2—10 cm，磨圆和分选较好 U2 粗砂砾石层，厚0.8—1.2 m，砾石磨圆度中等，分选一般，偶见粒径大于5 cm的巨砾，为冲洪积相堆积物 U3 中、细砾石层，偶夹土黄色粉土层，厚0.6—1.2 m，成层性一般，分选和磨圆很差，偶见棱角状砾石 U4 灰褐色砾石层，厚0.3—0.8 m，分选性和磨圆度较差，砾石多呈棱角状，粉砂含量相较于U3层较多，含较多碎石 TC-2 U1 土黄色粉砂层，厚1.5—2 m，成层性较好，偶含棱角状砾石 U2 砾石夹粉砂层，厚1—1.3 m，砾石磨圆一般，多呈棱角状，分选性较差，偶见厚约20 cm的砾石薄层 U3 灰黄色粗砂砾石层，厚1 m，粗砂含量明显多于U2层，砾石多呈次棱角状，分选和磨圆较差
下载: 导出CSV
表 2 钻孔岩性描述
Table 2. The description of drilling lithology
钻孔
编号岩性特征描述 1 0—70 m坡洪积碎石土层：主要为泥质粉砂岩，土为粉土；70—110.5 m砂卵砾石层：岩性以泥质粉砂岩为主，局部为花岗岩、砂岩 2 0—32.3 m坡积洪积碎石土层：以泥质粉砂岩为主，土为粉土；32.3—101.5 m冲洪积砂砾石层：泥质粉砂岩为主，局部花岗岩、砂岩 3 0—2.0 m粉土层：土黄色，手搓有砂感，硬塑—坚硬；2.0—100.1 m砂卵砾石层：以泥质粉砂岩、砂岩为主 4 0—52.6 m坡积洪积碎石土层：岩性为泥质粉砂岩，土为粉土；52.6—60 m砂卵砾石层：岩性为砂岩、泥质粉砂岩 5 0—18.5 m坡积洪积碎石土层：岩性为砂岩、泥质粉砂岩，土为粉土；18.5—60 m砂卵砾石层：岩性多呈砂岩，泥质粉砂岩 6 0—2.9 m粉土层：土黄色，干燥、松散；2.9—60 m砂卵砾石层：岩性为砂岩、泥质粉砂岩
下载: 导出CSV
-
[1] 吴胜和,冯文杰,印森林,等. 冲积扇沉积构型研究进展[J]. 古地理学报,2016,18(4):497-512 doi: 10.7605/gdlxb.2016.04.036Wu S H,Feng W J,Yin S L,et al. Research advances in alluvial fan depositional architecture[J]. Journal of Palaeogeography,2016,18(4):497-512 doi: 10.7605/gdlxb.2016.04.036 [2] 苗树清,胡宗凯,张玲,等. 洪积扇顶部活动走滑断裂的断错地貌分析——以新疆塔城盆地东缘阿合别斗河冲洪积扇为例[J]. 地震地质,2021,43(3):488-503 doi: 10.3969/j.issn.0253-4967.2021.03.002Miao S Q,Hu Z K,Zhang L,et al. Geomorphic analysis of strike-slip faulting at the top of alluvial fan:A case study at Ahebiedou river on the eastern margin of Tacheng Basin,Xinjiang,China[J]. Seismology and Geology,2021,43(3):488-503 doi: 10.3969/j.issn.0253-4967.2021.03.002 [3] 张润,杨劲松,赵华,等. 全新世以来大青山山前冲洪积扇的期次划分及其影响因素[J]. 干旱区资源与环境,2020,34(9):95-101 doi: 10.13448/j.cnki.jalre.2020.245Zheng R,Yang J S,Zhao H,et al. The period division and influencing factors of the alluvial fans in front of the Daqing Mountains since Holocene[J]. Journal of Arid Land Resources and Environment,2020,34(9):95-101 doi: 10.13448/j.cnki.jalre.2020.245 [4] 白毛伟,谢小平,陈芝聪,等. 龙门山北东段山前涪江第四纪冲洪积扇地貌演化及其构造响应[J]. 沉积学报,2017,35(1):85-92 doi: 10.14027/j.cnki.cjxb.2017.01.009Bai M W,Xie X P,Cheng Z C,et al. Geomorphological evolution of quaternary alluvial fans and its response to tertonic activity along the Fujiang River,Northeastern Longmen mountains[J]. Acta Sedimentologica Sinica,2017,35(1):85-92 doi: 10.14027/j.cnki.cjxb.2017.01.009 [5] 高帅坡,冉勇康,吴富峣,等. 利用无人机摄影测量技术提取复杂冲积扇面构造活动信息——以新疆巴里坤盆地南缘冲积扇面为例[J]. 地震地质,2017,39(4):793-804 doi: 10.3969/j.issn.0253-4967.2017.04.013Gao S P,Ran Y K,Wu F Y,et al. Using UAV photogrammetry technology to extract information of tectonic activity of complex alluvial fan:A case study of an alluvial fan in the southern margin of Barkol Basin[J]. Seismology and Geology,2017,39(4):793-804 doi: 10.3969/j.issn.0253-4967.2017.04.013 [6] 田建梅,李有利,司苏沛,等. 中条山北麓中段洪积扇上全新世断层陡坎的发现及其新构造意义[J]. 北京大学学报(自然科学版),2013,49(6):986-992Tian J M,Li Y L,Si S P,et al. Discovery and neotectonic significance of fault scarps on alluvial fans in the middle of northern piedmont of the Zhongtiao mountains[J]. Acta Scientiarum Naturalium Universitatis Pekinensis,2013,49(6):986-992 [7] 张维岐,廖玉华,潘祖寿,等. 初论贺兰山前洪积扇断层陡坎[J]. 地震地质,1982,4(2):32-34Zhang W Q,Liao Y H,Pan Z S,et al. On the piedmont scarp in diluvial fan of Mt. Helanshan[J]. Seismology and Geology,1982,4(2):32-34 [8] 王萍,卢演俦,丁国瑜,等. 甘肃疏勒河冲积扇发育特征及其对构造活动的响应[J]. 第四纪研究,2004,24(1):74-81 doi: 10.3321/j.issn:1001-7410.2004.01.009Wang P,Lu Y C,Ding G Y,et al. Response of the development of the Shule River alluvial fan to tectonic activity[J]. Quaternary Sciences,2004,24(1):74-81 doi: 10.3321/j.issn:1001-7410.2004.01.009 [9] 刘飞,李有利,雷惊昊,等. 青藏高原东北缘永昌南山北麓洪积扇对气候变化与构造运动的响应[J]. 海洋地质与第四纪地质,2019,39(4):163-173 doi: 10.16562/j.cnki.0256-1492.2019030201Liu F,Li Y L,Lei J H,et al. Response of alluvial fans to climatic changes and fault acticities in the north front of South Yongchang Mountains,Northeast margin of Tibet Plateau[J]. Marine Geology & Quaternary Geology,2019,39(4):163-173 doi: 10.16562/j.cnki.0256-1492.2019030201 [10] 江娃利,聂宗笙,张康富. 山西交城断裂错断全新世洪积扇[J]. 地震地质,1992,14(3):216-290Jiang W L,Nie Z S,Zhang K F. The dislocated Holocene alluvial-diluvial fans related to the activity of the Jiaocheng fault in Shanxi Province[J]. Seismology and Geology,1992,14(3):216-290 [11] 江娃利. 北京平谷地区地表陡坎的成因识别[J]. 地震地质,1999,21(4):309-315 doi: 10.3969/j.issn.0253-4967.1999.04.003Jiang W L. On identifying the formation mechanism of surface scarps in Pinggu area of Beijing[J]. Seismology and Geology,1999,21(4):309-315 doi: 10.3969/j.issn.0253-4967.1999.04.003 [12] 谭美娟. 河西走廊榆木山东麓第四纪地层研究[D]. 北京: 中国地质大学（北京）, 2016Tang M J. Study on Quaternary strata in Hexi Corridor of the eastern Yumu Mountain[D]. Beijing: China University of Geosciences （Beijing）, 2016 [13] 朱望琼. 河西走廊榆木山东麓河流地貌研究[D]. 北京: 中国地质大学（北京）, 2016Zhu W Q. A Study on the river landform of the east foothills of Yumu in the Hexi Corridor[D]. Beijing: China University of Geosciences （Beijing）, 2016 [14] 李玉龙,邢成起. 河西走廊地质构造基本特征以及榆木山北麓与黑河口上龙王活断层研究[J]. 西北地震学报,1988,10(2):35-47Li Y L,Xin C Q. Research on the fundamental characteristics of the geological structures of the Hexi Corridor and the active faults of the northern and eastern flank of the Yumushan mountain[J]. Northwestern Seismological Journal,1988,10(2):35-47 [15] 冉勇康,李志义,尤惠川,等. 河西走廊黑河口断层上的古地震及年代研究[J]. 地震地质,1988,10(4):118-126Ran Y K,Li Z Y,You H C,et al. The study and dating of paleoearthquake along Heihekou fault in Hexi Corridor[J]. Seismology and Geology,1988,10(4):118-126 [16] 金卿. 榆木山断裂带晚第四纪构造活动与大震危险性评价[D]. 兰州: 中国地震局兰州地震研究所, 2011Jin Q. Study on activity in late Quaternary and the earthquake risk assessment of the Yumu Mountain fault zone[D]. Lanzhou: Lanzhou Institute of Seismology, CEA, 2011 [17] 庞炜,谢超,李瑞莎,等. 祁连山—河西走廊西段强震复发概率模型及强震潜势评估[J]. 震灾防御技术,2021,16(2):272-282 doi: 10.11899/zzfy20210206Pang W,Xie C,Li R S,et al. Probability model for strong earthquake recurrence and estimates of seismic potential in western Qilian Mt.-Hexi Corridor[J]. Technology for Earthquake Disaster Prevention,2021,16(2):272-282 doi: 10.11899/zzfy20210206 [18] 庞炜,何文贵,张波. 临泽断裂新活动特征初步研究[J]. 地震研究,2019,42(1):120-132,152Pang W,He W G,Zhang B. Preliminary study of new faulting characteristic of the Linze fault[J]. Journal of Seismological Research,2019,42(1):120-132,152 [19] 李有利,李保俊,杨景春. 甘肃张掖黑河口断层晚更新世晚期以来的活动[J]. 北京大学学报(自然科学版),1995(3):351-357Li Y L,Li B J,Yang J C. Late Quaternary movement on the Heihekou fault,West Gansu,China[J]. Acta Scientiarum Naturalium Universitatis Pekinensis,1995(3):351-357 [20] 高利东,赵胜金,杨海星,等. 霍林河地区遥感影像线性构造解译[J]. 西部资源,2017(6):123-126Gao L D,Zhao S J,Yang H X,et al. Linear structure interpretation of remote sensing image in Huolinhe area[J]. Western Resources,2017(6):123-126 [21] 李攀峰,赵铁虎,齐君,等. 利用遥感数据解译蓬莱地区的主要线性构造[J]. 海洋地质前沿,2014,30(12):36-40 doi: 10.16028/j.1009-2722.2014.12.006Li P F,Zhao T H,Qi J,et al. Main linear structures in Penglai area identified based on remote sensing data[J]. Marine Geology Frontiers,2014,30(12):36-40 doi: 10.16028/j.1009-2722.2014.12.006 [22] 韩玲,王润平. 武都—文县地区遥感影像线性构造解译[J]. 地球科学与环境学报,2008,30(4):434-437 doi: 10.3969/j.issn.1672-6561.2008.04.019Han L,Wang R P. Remote sensing image interpretation of linear tectonics in Wudu-Wenxian area[J]. Journal of Earth Sciences and Environment,2008,30(4):434-437 doi: 10.3969/j.issn.1672-6561.2008.04.019 [23] 刘瑞国. 遥感解译线性构造与地质构造对比研究[J]. 中国煤炭地质,2018,30(4):71-74Liu R G. Comparative study of remote sensing interpreted lineament and geological structure[J]. Coal Geology of China,2018,30(4):71-74 [24] 邹斌文,马维峰,龙昱,等. 基于ArcGIS的条带剖面提取方法在地貌分析中的应用[J]. 地理与地理信息科学,2021,27(3):42-44 doi: 10.3969/j.issn.1672-0504.2021.03.007Zou B W,Ma W F,Long Y,et al. Extraction method of swath profile based on ArcGIS and its application in landform analysis[J]. Geography and Geo-Information Science,2021,27(3):42-44 doi: 10.3969/j.issn.1672-0504.2021.03.007 [25] 邓萍. 怎样阅读工程地质勘测报告[J]. 建筑工人,2001(10):40-42 doi: 10.3969/j.issn.1002-3232.2001.10.034Deng P. How to read engineering geological survey report[J]. Builders’ Monthly,2001(10):40-42 doi: 10.3969/j.issn.1002-3232.2001.10.034 [26] Hetzel R,Tao M X,Stokes S,et al. Late Pleistocene/Holocene slip rate of the Zhangye thrust(Qilian Shan,China)and implications for the active growth of the northeastern Tibetan Plateau[J]. Tectonics,2004,23(6):TC6006 [27] 曹喜林,胡小飞,潘保田,等. 三角剪切断层传播褶皱在祁连山北缘断裂中的应用:以黑河口断层为例[J]. 第四纪研究,2016,36(4):870-883 doi: 10.11928/j.issn.1001-7410.2016.04.08Cao X L,Hu X F,Pan B T,et al. Application of trishear fault-propagation folding to the north frontal thrust of the Qilian Shan mountains:An example from the Heihekou fault[J]. Quaternary Sciences,2016,36(4):870-883 doi: 10.11928/j.issn.1001-7410.2016.04.08 [28] 陈文彬. 河西走廊及邻近地区最新构造变形基本特征及构造成因分析[D]. 北京: 中国地震局地质研究所, 2003: 48-52Chen W B. Principal features of tectonic deformation and their generation mechanism in the Hexi Corridor and its adjacent regions since Late Quaternary[D]. Beijing: Institute of Geology, China Earthquake Administration, 2003: 48-52 -
